XCMG XS43 Concrete Machinery Concrete Pump
Model:
XS43
View All >
Category:
Concrete Machinery
Product:
Concrete Pump
Brand Name:
XCMG
Dimension (mm):
11120*2500*3930mm
Operating weight (kg):
30000kg
Origin:
China
Key Attributes
Vertical Reach:
42.1m
Horizontal Reach:
37.3m
Reach Depth:
29m
Unfolding Reach:
230°
Rated Pumping Output:
130m³/h
Maximum Pumping Pressure:
8MPa
Max Power:
257kW
Max Speed:
89km/h
Displacement:
7.36L
Filling Height:
1580mm
Packaging & Shipping
Overall Dimensions (L×W×H):
11120*2500*3930mm
Overall Weight:
30000kg
Shipping Method:
Bulk shipment
Delivery Period:
1 month
Certificate:
Yes
Origin:
China
HS Code :
8705909100
Detailed Specifications

Mounted Concrete Boom Pump is a convenient and efficient dedicated construction machinery for transporting and concreting concrete, which has features of short construction period, large spreading range, low labor strength and operation in confined space. It is widely used in high-rise construction, underground construction and large concrete construction.

1.Ultimately Safe Boom

All-around technical methods are used to make XCMG diesel concrete pump machine HB43V safer and more reliable. A new generation of micro-control technology is used to make boom operation steadier and more accurate.

2.Lower Structurre of High Rigidity

On the basis of the design concept of high rigiditystructure, simulative calculation and testing offull-work-condition loading make Sinotruk HOWO chassis structuredeformation smaller and overall work stability.

3.Hydraulic System of Outstanding Performance

MPS (micro shock) reversing buffering technology;The buffering process is steadier and more reliable, with smaller impact;The reversing time is shortened to be less than 0.1s and the efficiency is improved by more than 6%.SCHWING Germany’s hydraulic technology quintessence truly realizes fully-hydraulic reversing, in which self-adaption control in fully-hydraulic closed-loop is realized, with no need for any electrical components, more effective, steadier and zero-pollution.

4.Advantages of Sinotruk/BENZ chassis

No matter from the economic benefit, loading quality, or overload capacity, Sinotruk/BENZ chassis in the industry has a leading technology and brand advantage.

CategoryItemUnitXS43
Overall parameterOutline dimensionmm11260×2500×3990
Overall weightkg31000
Model-ZZS5387THB46ME1
ChassisManufacturer-Sinotruk
Maxspeedkm/h89
Max - gradeability%35
Wheelbasemm4400 + 1400
Tire-315/80R22.5
EngineModel-MC07H35 - 50
Max. powerkw257
DisplacementL10.518
Emission standard-Euro Ⅲ/Euro Ⅴ
Pumping systemTheoretical outputm³/h120
Concrete pumping pressureMPa8
Theoretical strokesTime/min24 - 27
Inner diameter × stroke of delivery cylinder-φ260×2000
Max. diameter of pumped maximum aggregatemm40
Feeding heightmm1580
Concrete slump rangecm8 ~ 23
Placing boomReachable heightm43
Reachable depthm29
Slewing radiusm37.3
Slewing angle°±270
Unfolding angle of first - stage boom°90
Unfolding angle of second - stage boom°180
Unfolding angle of third - stage boom°180
Unfolding angle of fourth - stage boom°230
Unfolding angle of fifth - stage boom°210
Stabilizer spanLongitudinal span of stabilizermm7700
Transverse span of front stabilizermm7300
Transverse span of rear stabilizermm7740
OthersDistribution valve type-German Rock - valve
Lubrication method-Automatic lubrication
Control mode-Manual/Remote control
Volume of water tankL400
