XCMG XE155GA Earthmoving Machinery Crawler Excavator
Model:
XE155GA
View All >
Category:
Earthmoving Machinery
Product:
Crawler Excavator
Brand Name:
XCMG
Dimension (mm):
7,825*2,590*2,950mm
Operating weight (kg):
14,600kg
Origin:
CHINA
Key Attributes
Bucket Capacity:
0.32m³
Max. Digging Height:
8,640mm
Max. Digging Depth:
5,555mm
Engine Brand:
Cummins
Engine Power:
96kw
Digging Force:
107KN
Maximum digging radius:
8,310mm
Minimum turning radius:
2,445mm
Boom length:
4,600mm
Arm Length:
2,520mm
Packaging & Shipping
Overall Dimensions (L×W×H):
7,825*2,590*2,950mm
Overall Weight:
14,600kg
Shipping Method:
Sea freight
Delivery Period:
In stock
Certificate:
CE Certificate
Origin:
CHINA
HS Code :
8429521200
Detailed Specifications
ParameterSpecification / Value
ModelXE155GA Crawler Excavator
Operating Weight14,600 kg
Bucket Capacity0.32 – 0.72 m³
Engine Rated Power / Speed96 kW @ 2200 rpm
Engine ModelF4.5CS4129 (4-cylinder, turbocharged, intercooler)
Displacement4.5 L
Maximum Torque / Speed570 N·m @ 1300 rpm
Travel Speed (High / Low)5.3 / 3.0 km/h
Swing Speed~11 r/min
Gradeability≤ 35%
Ground Pressure~37 kPa
Bucket Digging Force107 kN
Arm/Stick Digging Force80 kN
Maximum Tractive Force134 kN
Fuel Tank Capacity~240 L
Hydraulic System – Main Pump2 × variable pump, 129 L/min each
Relief Valve Setting Pressure34.3–37 MPa
Travel System Pressure~34.4 MPa
Swing System Pressure~25 MPa
Pilot System Pressure~3.9 MPa
Overall Length~7,825 mm
Overall Width~2,590 mm
Overall Height~2,950 mm
Crawler Track Width~600 mm
Track Length on Ground~3,648 mm
Crawler Gauge~1,990 mm
Clearance Under Counterweight~931 mm
Minimum Ground Clearance~466 mm
Min. Tail Swing Radius~2,360 mm
Max. Digging Height~8,620 mm
Max. Dump Height~6,175 mm
Max. Digging Depth~5,545 mm
Max. Digging Reach~8,295 mm
Max. Vertical Wall Digging Depth~4,575 mm
