ZOOMLION ZAT1300V 130 Lifting Machinery Truck Crane

See Full Gallery (5-photos & videos)

Model:

ZAT1300V 130

View All >

Category:

Lifting Machinery

Product:

Truck Crane

Brand Name:

ZOOMLION

Dimension (mm):

15660×3000×4000

Operating weight (kg):

60000

Origin:

china

Min Order Quantity:

1 Unit

Delivery Time:

Manual Download

Summary

Max. Working Radius:

114

Load Moment:

1505

Boom Length:

13.5 - 72m

Mounting Position:

Overall Dimensions:

15660×3000×4000 mm

Hydraulic Pressure:

Max. Lifting Capacity:

10t / 22,000 lbs

Max. Hoisting Capacity at Jib End:

2.5t

Max. Lifting Height:

40m

Max. Jib Length:

60m

Specifications

Packaging & Shipping

Overall Dimensions (L×W×H):

15660×3000×4000

Overall Weight:

60000

Shipping Method:

heavy cargo shipping

Delivery Period:

Certificate:

tuv

Origin:

china

HS Code :

8429510000

Details

Item	Unit	Value	Parameters
Working performance	Max. rated lifting capacity	kg	130000
	Max. load moment of basic boom	kN.m	4704
	Max. load moment of max. length boom boom(fully extended)	kN.m	1505
	Max. load moment of basic boom	m	13.0
	Max. lifting height of main boom	m	72
	Max. lifting height of jib	m	87/(95)
Working speeds	Max. hoist rope speed(Main winch)	m/min	114
	Max. hoist rope speed(Auxiliary winch)	m/min	74
	Boom derricking up time	s	94
	Boom extendingt time	s	860
	Max. Slewing speed	r/min	1.4
Driving parameters	Max. driving speed	km/h	75
	Max. gradeability	%	40
	Turning diameter	m	≤20
	Min. ground clearance	mm	305
	Limits for exhaust pollutants and smoke		Conform to related standards
	Fuel consumption per hundred kilometers	L	76
Mass	Deadweight in driving condition	kg	60000
	Complete vehicle kerb mass	kg	59805
	Load on axles 1,2 and 3	kg	12000
	Load on axles 4 and 5	kg	12000
Dimensions	Overall dimensions(L×W×H)	mm	15660×3000×4000
	Outrigger spread(L)	m	8.43
	Outrigger spread(W)	m	Fully extended:7.8, Intermediately extended:5.3
	Main boom length	m	13.5 - 72
	Boom angle	°	-0.5 - 82
	Jib length	m	11,18.6
	Jib + extension length	m	26.6
	Offset	°	0,30
